Cycling has a reputation for being gentle on the joints. It’s low impact, smooth, rhythmic, and often prescribed as the perfect exercise for people who want to avoid pounding their knees with high-impact sports like running.

But ask around any group of regular cyclists, and you’ll hear the same story: knee pain creeps in sooner or later. That dull ache after a long ride, the sharp stab on a climb, or the stiffness the morning after — all can turn what should be an enjoyable workout into a frustrating setback.

The irony is cruel: the very activity meant to protect your knees can sometimes be the thing that hurts them.

The good news? Almost all cycling-related knee pain has a clear cause — and most of the time, a clear solution. With the right adjustments, strength work, and awareness, you can keep your knees happy and pedal pain-free for years.

Let’s break it down step by step.

Why Do Cyclists Get Knee Pain?

Think of your knee as a hinge on a door. Its main job is simple: bend and straighten. Unlike your shoulder or hip, it doesn’t like twisting, side-to-side motion, or being pulled out of line.

Cycling, with its repetitive pedal strokes — thousands per ride, millions per year — magnifies even the tiniest imbalance. A saddle that’s 5mm too low, a cleat angle that’s off by just a few degrees, or a weak muscle in your hips can be enough to irritate the joint.

Pain is your body’s way of saying:
“Something in your setup, your body, or your training habits is forcing this hinge out of its natural path.”

And where that pain shows up is often the biggest clue.

What Is Your Knee Telling You?

Location matters. Different types of knee pain often point to different underlying issues:

• Front of the knee (anterior pain) → Often called “cyclist’s knee”, usually from a saddle that’s too low or too far forward, overloading the patella (kneecap).

• Back of the knee (posterior pain) → Usually from a saddle that’s too high, forcing your leg to overextend with each stroke.

• Inside of the knee (medial pain) → Often from cleats forcing your foot into an unnatural angle, or from collapsed arches needing support.

• Outside of the knee (lateral pain) → Commonly linked to IT band irritation or cleat misalignment that twists your knee outward.

Key takeaway: The where of the pain is your first detective clue. From there, you can investigate further.

The 3 Big Causes of Cycling Knee Pain

Nearly every knee issue on the bike boils down to one (or a combination) of these three areas:

1. Your Bike Setup → Saddle height, cleats, crank length, handlebars.

2. Your Body’s Condition → Strength, flexibility, muscle imbalances, foot support.

3. Your Training Habits → Mileage, cadence, gearing, recovery.

Let’s go deeper into each.

1. Your Bike Setup

Your position on the bike is the number one factor in knee health. If the geometry isn’t right for your body, pain is almost inevitable.

Saddle Height and Position

This is the biggest culprit. Even a few millimeters can make or break your comfort.

• Too high: You’ll feel a pulling sensation behind your knee. The joint is overextending, straining tendons.

• Too low: You’ll feel pressure at the front of the knee. The joint stays too bent, crushing the patella with each stroke.

• Too far forward: Overloads the quads, pushing the knee cap into the joint.

• Too far back: Can make pedaling inefficient and strain the hamstrings.

Quick Test for Saddle Height:

• Sit on the bike with your heel on the pedal at its lowest point.

• Your leg should be just straight.

• When clipped in (ball of foot on pedal), this leaves the ideal slight bend in the knee (~25–35°).

Adjustment Tips:

• Pain in front? Raise saddle 5mm.

• Pain in back? Lower saddle 5mm.

• Make one change at a time, ride a few days, reassess.

Forwards/Backwards Test:

• Put pedals level (3 o’clock / 9 o’clock).

• Drop a plumb line from your front knee cap.

• It should intersect the pedal axle.

• Too far ahead? Slide saddle back slightly.

Cleat Alignment

Cleats lock your foot into a fixed path. A tiny misalignment here repeats thousands of times per ride — no wonder the knee complains.

Common mistakes:

• Cleats too far forward → extra calf strain, back-of-knee pain.

• Cleat angle off → twists the knee, causing inside or outside pain.

• Stance too narrow or too wide → messes with natural knee tracking.

Fixes:

• Start with cleat under the ball of your foot.

• If pain in back of knee → move cleat slightly backward.

• If outside knee pain → allow heel-out rotation.

• If inside knee pain → allow heel-in rotation.

• Use cleats with some “float” (natural wiggle room).

📸 Pro tip: Take a photo of your cleats before adjusting. Always adjust in tiny increments.

Crank Length and Handlebar Position

Less obvious, but they matter.

• Cranks too long: Force the knee into deeper bends, straining the front.

• Bars too low/far: Rounds your back, shifts weight forward, and indirectly affects knee tracking.

Rules of thumb:

• Riders under ~5’8” often benefit from 170mm or shorter cranks.

• If constantly stretched, try raising bars with a 5–10mm spacer or using a shorter stem.

2. Your Body’s Condition

Sometimes, the bike isn’t the only problem. Your body itself may be unbalanced.

Muscle Weakness

Weak glutes, quads, or core muscles can cause the knee to drift off its natural line during the pedal stroke.

Fixes:

• Glutes: Bridges, squats, single-leg work.

• Quads: Step-ups, lunges.

• Core: Planks, side planks.

• 2–3 times per week is enough to see results.

Tightness & Imbalances

Tight hamstrings or IT bands tug on the knee joint. Many cyclists neglect stretching.

Fixes:

• Hamstring stretches: Hold 30 seconds, no bouncing.

• Foam roll IT band gently, before and after rides.

• Stretch quads and hip flexors regularly.

Foot Support

Flat shoes = collapsed arches = knee tracking issues.

Fixes:

• Upgrade insoles to cycling-specific ones.

• Consider cleat wedges if you notice your knee drifting inward or outward.

• If you suspect leg-length difference, experiment with shims under one cleat.

3. Your Training Habits

Even with the perfect bike fit and strong muscles, bad habits on the bike can wreck your knees.

Doing Too Much, Too Soon

Overuse is the #1 training mistake. Joints, tendons, and ligaments adapt slower than muscles.

Fixes:

• Follow the 10% rule → don’t increase weekly mileage more than 10%.

• Build gradually, especially early in the season.

Pushing Big Gears

Grinding a heavy gear at low cadence puts massive strain on the knee.

Fixes:

• Spin, don’t mash. Aim for 90–100 rpm on flats.

• Drop to an easier gear before you hit a climb.

Poor Pedal Technique

Think of smooth circles, not jerky squares. An uneven stroke stresses the joint.

Fixes:

• Use cadence sensors or bike computers to monitor.

• Practice pedalling drills: one-leg spins on the trainer, high-cadence sprints.

When to See a Professional

If you’ve tried the basics (saddle height, cleats, strength work) and pain persists — especially if you see swelling — don’t tough it out. A bike fit specialist or physiotherapist can spot details you can’t.

Yes, it’s an investment. But so is being able to keep riding for decades.

Cycling knee pain can feel like a cruel joke, but it’s almost always solvable. Think of it like detective work:

• Where’s the pain? → Front, back, inside, outside.

• Check the bike. → Saddle, cleats, bars, cranks.

• Check the body. → Strength, flexibility, balance.

• Check your training. → Load, cadence, technique.

Make small changes, give your body time to adapt, and don’t be afraid to get professional input if the problem lingers.

Your knees are designed to last a lifetime. Treat them well, and they’ll carry you through thousands of joyful miles, pain-free.
